CT-6S 12VDC
6,000
BTUs
115V / 12VDC
Volts
NMEA2000
Soft Start
Compact
Titanium Coil
Cooling
Heating
Quiet
Universal Board
Turbo Blower
Modular
Wi-fi Compatible
Robust Electrical Box
Stainless Steel Base
NMEA2000
ABS Rust Free Base
Reusable Air Filter
Soft Start
Unit Drawings
Specifications
Capacity (BTU)
6,000
Voltage (V)
115V / 12VDC
Cycle (Hz) / Phase (Ph)
50-60 / 1
Input: Cool (A)
4.5 @ 120V
Input: Heat (A)
5.6 @ 120V
Fuse Max/Min (A)
Locked Rotator Amps (A)
Seawater Inlet Connection (in/mm)
5/8 / 16
Seawater Outlet Connection (in/mm)
5/8 / 16
Refrigerant Type
R410A
Net Weight (lbs/kg)
Width (in/mm)
15.28 / 388
Height (in/mm)
12 / 305
Depth (in/mm)
Duct Ring Size (in/mm)
Min. Return Air Grille (sq in /sq cm)
64 / 413
Min. Supply Air Grille (sq in /sq cm)
32 / 206
NMEA 2000 compatible
This NMEA 2000 compatible unit delivers seamless integration with Garmin Empirbus, OneHelm, and Raymarine YachtSense. Control multiple HVAC systems directly from your vessel’s MFD and digital switching systems — no extra displays required.
Soft Start
This unit is compatible with Micro-Air EasyStart soft starters, reducing starting amps by up to 75%. Enjoy reliable performance with continuous runtime diagnostics that monitor for stalls, overcurrent, miswiring, short cycles, and more.
Installation Diagram
Explore our installation diagram to understand how CTM Marine units integrate into your vessel.
CT-6S 12VDC
Seamless swap
Compatible models below
Brand
OEM Part Number
Description
We’re actively working on updating compatible part numbers for non-CTM marine models. But you can find compatible units in our new search tool below:
Retrofit Search Tool
Compatible With Most Thermostats
Easy Touch
Elite II
Passport I/O
